Cajas de conexion
Cerrar
Cerrar
TCT301 – 1 Channel – Triaxial Sensor Termination Boxes
- Case Material: Polycarbonate
- Inputs: Terminal Block 5 Connections per Channel (X, Y, Z, Common, GND)
- Rating: NEMA 4X
- Resistance: Resistant to Hose Directed Fluid
- Dimensions: 4.72 x 2.72 x 2.52 in
(120 x 69 x 64 mm)
Cerrar
TSB-MOD12 – Triaxial switch module with 12 triaxial inputs, three BNCs
- Case Material: PVC
- Inputs: Terminal Block
- Rating: N/A
- Resistance: N/A
- Dimensions: 3.54 x 4.06 x 7.99 in
(90 x 103 x 203 mm)
Cerrar
Cerrar
TSB-MOD4 – Triaxial switch module with 4 triaxial inputs, three BNCs
- Case Material: PVC
- Inputs: Terminal Block
- Rating: N/A
- Resistance: N/A
- Dimensions: 4.02 x 3.94 x 2.76 in
(102 x 100 x 70 mm)
Cerrar
Cerrar
TSB1000 – Fiberglass Switch Box, Triaxial Output, Modular, 4 Triaxial Sensor
- Case Material: Fiberglass
- Inputs: Terminal Block, 5 Terminations per Triaxial Sensor (X +, Y +, Z +, COM, GND)
- Rating: NEMA 4X
- Resistance: Resistant to Hose Directed Fluid and Corrosion
- Dimensions: 7.72 x 9.61 x 4.61 in
(196 x 244 x 117 mm)
Cerrar
TSB2000 – Stainless Steel Switch Box, Triaxial Output, Modular, 4 Sensor
- Case Material: Stainless Steel
- Inputs: Terminal Block, 5 Terminations per Triaxial Sensor (X +, Y +, Z +, COM, GND)
- Rating: NEMA 4X
- Resistance: Resistant to Hose Directed Fluid and Corrosion
- Dimensions: 6.69 x 8.31 x 4.21 in
(170 x 211 x 107 mm)
Cerrar
TSB3000 – Fiberglass Switch Box, Triaxial Output, Modular, 12 Triaxial Sensor
- Case Material: Fiberglass
- Inputs: Terminal Block, 5 Terminations per Triaxial Sensor (X +, Y +, Z +, COM, GND)
- Rating: NEMA 4X
- Resistance: Resistant to Hose Directed Fluid and Corrosion
- Dimensions: 11.65 x 13.74 x 6.93 in
(296 x 349 x 176 mm)
Cerrar
TSB4000 – Stainless Steel Switch Box, Triaxial Output, Modular, 12 Triaxial Sensor
- Case Material: Stainless Steel
- Inputs: Terminal Block, 5 Terminations per Triaxial Sensor (X +, Y +, Z +, COM, GND)
- Rating: NEMA 4X
- Resistance: Resistant to Hose Directed Fluid and Corrosion
- Dimensions: 10.00 x 13.50 x 7.24 in
(254 x 343 x 184 mm)
Cerrar
TSB6000 – 12 Channel – Stainless Steel Sloped Top Enclosure, Triaxial Output, Modular, 4 Sensor (12 Channel)
- Case Material: Stainless Steel
- Inputs: Terminal Block, 5 Terminations per Triaxial Sensor (X +, Y +, Z +, COM, GND)
- Rating: NEMA 4X
- Resistance: Resistant to Hose Directed Fluid and Corrosion
- Dimensions: 6.24 x 13.75 x 6.18 in
(158.5 x 349.3 x 156.9 mm)
